GXP® DREN 1200 PLUS

New Insulation and drainage membrane

GXP® Dren 1200 Duo is a waterproof membrane extruded from high density polyethylene (HDPE), 1,2 mm thick, thermally joined with polyethylene geotextile made from continuous fibres 140 g/m² on the top side and polypropylene or polyester geotextile 250 gm² on the bottom side.

Used as:

  • An insulation and drainage layer for retaining and foundation walls, bridge abutments, waste dumps, ash collection tanks, floor slabs, tunnels, draining channels, green roofs
  • A separation and drainage shield in road, railway and airport foundation constructions
  • An increased friction angle between the base and the geocomposite prevents skidding of the geocomposite from slopes under the pressure of the ground

Advantages

  • A layer protecting against mechanical damage of insulation layers
  • A draining layer for high loads
  • An anti-root layer
  • A sealing and degassing layer for:
    • rubbish dumps
    • waste collection sites
    • industrial tanks

Technical Data

Technical Data
Geocomposite weight1500 g/m2
Compression strength1500 kN/m2
Embossing height8 mm
HDPE membrane thickness1200 μm
HDPE membrane surface mass1500 g/m2
Air volume between textile and membrane5,3 l/m2
Drainage capacity2,1 l/m/s
Width4 x 10 m, 4 x 20 m
Temperature resistance-40 do +80oC

Photos

For Download

2.02 MB | pdf
GRILTEX_GXP_DREN _1200_DUO
Download
9.31 MB | pdf
KARTA PRODUKTU
Download
