GXP® 3 GRID

Insulation and ventilation of damp walls

The pressed membrane made of high density polyethylene (HDPE), with the basis weight of 600 g/m², with a stuck-on grid, basis weight of 50 g/m², is assigned to control the dampness of basements and enables their maintenance. The structure of embossings facilitates breathing of damp walls, providing a tight barrier and dry plaster (finishing).

Advantages

  • Very high compression strength (15 t/m² ) and breakdown strength
  • Limits plaster cracking over time
  • Facilitates breathing of damp walls
  • The transparency of the foil makes it possible to see the wiring system underneath the layer

Technical Data

Technical Data
Composite weight650 g/m2
MaterialHDPE
Compression strength150 kN/m2
Embossing height8 mm
Number of embossings1150 per m2
Air space between buckets5,51 l/m2
Temperature resistance-40 to +80°C
Membrane thickness600 µm

Photos

For Download

5.32 MB | pdf
GRILTEX_ULOTKA_GXP_3W_GRID_ENG_preview
Download

Application

Housebuilding industry
