GXP® PLUS FIX
Innovative geomembrane with integrated mounting belts
The membrane GXP® Plus Fix, made of high density polyethylene (HDPE), with the basis weight of 800 – 1200 g/m2, integrated with the mounting belts, is assigned to be joined with another geosynthetic, such as: geogrid, geomesh, geograte, geomat, etc. The foil’s embossings constitute a natural protection for the geograte against sliding on the (flat) foil. The geomembrane equipped with integrated mounting belts not only guarantees tightness, strength and quick assembly, but it also secures the humus layer in case of out-of– ordinary precipitation.
- Durable and effective mounting – it prevents embankment landslides
- No necessity of geomembrane perforation during mounting – maintained hydroinsulation
- Shorter mounting time
- Smaller involvement of human labour
- It enables the recipient to develop a competition advantage on the market of construction works contracting.
|Weight||800g/m2||1 000 g/m2|
|Thickness||800 μm||1 000 μm|
|Compression strength||400 kN/m2||500 kN/m2|
|Temperature resistance||-40 do +80oC||-40 do +80oC|
