GXP® 3 GRID
Insulation and ventilation of damp walls
The pressed membrane made of high density polyethylene (HDPE), with the basis weight of 600 g/m², with a stuck-on grid, basis weight of 50 g/m², is assigned to control the dampness of basements and enables their maintenance. The structure of embossings facilitates breathing of damp walls, providing a tight barrier and dry plaster (finishing).
Advantages
- Very high compression strength (15 t/m² ) and breakdown strength
- Limits plaster cracking over time
- Facilitates breathing of damp walls
- The transparency of the foil makes it possible to see the wiring system underneath the layer
Technical Data
| Technical Data | |
|---|---|
| Composite weight | 650 g/m2 |
| Material | HDPE |
| Compression strength | 150 kN/m2 |
| Embossing height | 8 mm |
| Number of embossings | 1150 per m2 |
| Air space between buckets | 5,51 l/m2 |
| Temperature resistance | -40 to +80°C |
| Membrane thickness | 600 µm |
Photos
Housebuilding industry
